3-axis machining center immediate delivery VL-106

Sectores en los cuales se utiliza:

ARMAMENTOARMAMENTO

EDUCACIÓN / FORMACIÓNEDUCACIÓN / FORMACIÓN

FABRICANTE DE HERRAMIENTAFABRICANTE DE HERRAMIENTA INDUSTRIAL

MANTENIMIENTO MANTENIMIENTO

MECANIZADO GENERAL MECANIZADO GENERAL

MOLDE / MATRIZ MOLDE / MATRIZ / OTROS

SERVICIO DE INGENIERÍA Y FABRICACIÓN SERVICIO DE INGENIERÍA Y FABRICACIÓN

Physical characteristics

Ref.: VL-106 stock

Work table (WxL) 600x1200
X/Y/Z axis travel 1000/ 620/ 630
Speed ​​range 20 - 10000

Standard configuration

  • Linear guides and roller skates in the X/Y/Z axes
  • Pretensioned ball screws
  • Rigid threading
  • Workpiece Cooling System
  • Heat exchanger in the electrical panel
  • Auto power off
  • Complete fairing
  • Oil collector guides
  • Air seal on the spindle
  • Automatic lubrication system
  • RS232 interface
  • Air gun
  • electronic steering wheel
  • Leveling plugs
  • CE marking
Data sheet


Data sheet

Characteristics
Brand VURCON
Work table (WxL) mm 600x1200
Control FANUC 15"
X axis travel mm 1000
Y axis travel mm 620
Z axis travel mm 630
Max load admitted on the work table kg 800
Spindle-table distance mm 110 - 740
T-slots mm 5 slots/18 slots
Distance between slots mm 100
Main spindle cone BT40
Column distance - spindle center mm 667
Speed ​​range rpm 20 - 10000
main spindle drive straps
Main engine power at S6 kW fifteen
Cone balancing G1
Spindle precision mm ±0.005
Dynamic precision mm ±0.003
Standard tool holder MSA403 BT40
X axis servomotor power kW 3
Y axis servomotor power kW 3
Z axis servomotor power kW 3
X axis rapid feed m/min 36
Y axis rapid feed m/min 36
Z axis rapid feed m/min 32
Work progress mm/min 12000
Tool magazine type Double arm
Tool changer type Random
Tool capacity pc 32
Day. max. of tools with adjacent tool mm 78
Day. max without adjacent tool mm 120
Max weight supported tool kg 8
Max length of tool admitted mm 300
Tire consumption kg 6 - 8
Electrical consumption kva twenty
Required power 3-380V±10% 50Hz
Coolant pump flow l/min 30
Optimal ambient temperature range º 0 - 40
Optimum ambient humidity % 20 - 80
Fairing type Complete
X/Y/Z positioning precision mm ±0.008
X/Y/Z repositioning precision mm ±0.005
Dimensions mm 2850x2450x2850
Weight kg 7600

Data sheet

Characteristics
Brand VURCON
Work table (WxL) mm 600x1200
Control FANUC 0i MF
X axis travel mm 1000
Y axis travel mm 620
Z axis travel mm 630
Max load admitted on the work table kg 1000
Spindle-table distance mm 110 - 740
T-slots mm 5 slots/18 slots
Distance between slots mm 100
Main spindle cone BT40
Column distance - spindle center mm 667
Speed ​​range rpm 20 - 10000
main spindle transmission straps
Main engine power at S6 kW fifteen
Cone balancing G1
Spindle precision mm ±0.005
Dynamic precision mm ±0.003
Standard tool holder MSA403 BT40
X axis servomotor power kW 3
Y axis servomotor power kW 3
Z axis servomotor power kW 3
X axis rapid feed m/min 36
Y axis rapid feed m/min 36
Z axis rapid feed m/min 32
Work progress mm/min 12000
Tool magazine type Double arm
Tool changer type Random
Tool capacity pc 24
Day. max. of tools with adjacent tool mm 78
Day. max without adjacent tool mm 120
Max weight supported tool kg 8
Max length of tool admitted mm 300
Tire consumption kg 6 - 8
Electrical consumption kva twenty
Required power 3-380V±10% 50Hz
Coolant pump flow l/min 30
Optimal ambient temperature range º 0 - 40
Optimum ambient humidity % 20 - 80
Fairing type Complete
X/Y/Z positioning accuracy mm ±0.008
X/Y/Z repositioning precision mm ±0.005
Dimensions mm 2850x2450x2850
Weight kg 7600

Data sheet

Characteristics
Brand VURCON
Work table (WxL) mm 700x1400
Control FANUC 0i MF
X axis travel mm 1200
Y axis travel mm 700
Z axis travel mm 700
Max load admitted on the work table kg 800
Spindle-table distance mm 110 - 740
T-slots mm 5 slots/18 slots
Distance between slots mm 100
Main spindle cone BT40
Column distance - spindle center mm 667
Speed ​​range rpm 20 - 10000
main spindle drive straps
Main engine power at S6 kW fifteen
Cone balancing G1
Spindle precision mm ±0.005
Dynamic precision mm ±0.003
Standard tool holder MSA403 BT40
X axis servomotor power kW 3
Y axis servomotor power kW 3
Z axis servomotor power kW 3
X axis rapid feed m/min 36
Y axis rapid feed m/min 36
Z axis rapid feed m/min 32
Work progress mm/min 12000
Tool magazine type Double arm
Tool changer type Random
Tool capacity pc 24
Day. max. of tools with adjacent tool mm 78
Day. max without adjacent tool mm 120
Max weight supported tool kg 8
Max length of tool admitted mm 300
Tire consumption kg 6 - 8
Electrical consumption kva twenty
Required power 3-380V±10% 50Hz
Coolant pump flow l/min 30
Optimal ambient temperature range º 0 - 40
Optimum ambient humidity % 20 - 80
Fairing type Complete
X/Y/Z positioning accuracy mm ±0.008
X/Y/Z repositioning precision mm ±0.005
Dimensions mm 2850x2450x2850
Weight kg 7600

Data sheet

Characteristics
Brand VURCON
Work table (WxL) mm 700x1600
Control FANUC 0i MF
X axis travel mm 1400
Y axis travel mm 700
Z axis travel mm 700
Max load admitted on the work table kg 1100
Spindle-table distance mm 150-850
T-slots mm 5-18
Distance between slots mm 125
Main spindle cone BT50
Column distance - spindle center mm 766
Speed ​​range rpm 20 - 6000
main spindle drive straps
Main engine power at S6 kW 18.5
Cone balancing G1
Spindle precision mm ±0.005
Dynamic precision mm ±0.007
Standard tool holder MSA403 BT50
X axis servomotor power kW 3
Y axis servomotor power kW 3
Z axis servomotor power kW 3
X axis rapid feed m/min 24
Y axis rapid feed m/min 24
Z axis rapid feed m/min twenty
Work progress mm/min 6000
Tool magazine type MANIPULATOR
Tool changer type Random
Tool capacity pc 24
Day. max. of tools with adjacent tool mm 110
Day. max without adjacent tool mm 220
Max weight supported tool kg fifteen
Max length of tool admitted mm 350
Tire consumption kg 6 - 8
Electrical consumption kva twenty
Required power 3-380V±10% 50Hz
Coolant pump flow l/min 40
Optimal ambient temperature range º 0 - 40
Optimum ambient humidity % 20 - 80
Fairing type Complete
X/Y/Z positioning precision mm ±0.008
X/Y/Z repositioning precision mm ±0.005
Dimensions mm 3800(+1400 chip conveyor) ×2860×3160mm
Weight kg 11000

Data sheet

Characteristics
Brand VURCON
Work table (WxL) mm 850x1700
Control FANUC 0i MF
X axis travel mm 1500
Y axis travel mm 850
Z axis travel mm 850
Max load admitted on the work table kg 1600
Spindle-table distance mm 120 - 970
T-slots mm 5-18-125 + 2-18-100
Distance between slots mm 125 + 100
Main spindle cone BT50
Column distance - spindle center mm 935
Speed ​​range rpm 20 - 6000
Main engine power at S6 kW 18.5
Cone balancing G1
Spindle precision mm ±0.005
Dynamic precision mm ±0.007
Standard tool holder MSA403 BT50
X axis servomotor power kW 3
Y axis servomotor power kW 2
Z axis servomotor power kW 3
X axis rapid feed m/min 24
Y axis rapid feed m/min 24
Z axis rapid feed m/min fifteen
Work progress mm/min 8000
Tool magazine type Arm
Tool changer type Random
Tool capacity pc 24
Day. max. of tools with adjacent tool mm 110
Max weight supported tool kg fifteen
Max length of tool admitted mm 4.5
Tire consumption kg 6 - 8
Electrical consumption kva 35
Required power 380V±10% 50Hz
Coolant pump flow l/min 40
Optimal ambient temperature range º 10 - 40
Optimum ambient humidity % 20 - 80
Fairing type Complete
X/Y/Z positioning accuracy mm ±0.010
X/Y/Z repositioning precision mm ±0.005
Dimensions mm 4100+1400(chip extractor)×3100×3380
Weight kg 15800

Data sheet

Characteristics
Brand VURCON
Work table (WxL) mm 400x850
Control FANUC 0i MF
X axis travel mm 650
Y axis travel mm 400
Z axis travel mm 500
Max load admitted on the work table kg 400
Spindle-table distance mm 100-600
T-slots mm 5-18
Distance between slots mm 100
Main spindle cone BT40
Column distance - spindle center mm 623
Speed ​​range rpm 20-10000
main spindle drive straps
Main engine power at S6 kW fifteen
Cone balancing G1
Spindle precision mm ±0.008
Dynamic precision mm ±0.004
Standard tool holder MSA403 BT40
X axis servomotor power kW 1.2
Y axis servomotor power kW 1.2
Z axis servomotor power kW 2.5
X axis rapid feed m/min 48
Y axis rapid feed m/min 48
Z axis rapid feed m/min 32
Work progress mm/min 10000
Tool magazine type Double arm
Tool changer type Random
Tool capacity pc 24
Day. max. of tools with adjacent tool mm 80
Day. max without adjacent tool mm 120
Max weight supported tool kg 8
Max length of tool admitted mm 300
Tire consumption kg 6-8
Electrical consumption kva twenty
Required power 380V±10% 50Hz
Coolant pump flow l/min 30
Optimal ambient temperature range º 0-40
Optimum ambient humidity % 20-80
Fairing type Complete
X/Y/Z positioning accuracy mm ±0.008
X/Y/Z repositioning precision mm ±0.004
Dimensions mm 2100x2300x2700
Weight kg 4100

Data sheet

Characteristics
Brand VURCON
Work table (WxL) mm 500x1000
Control FANUC 0i MF
X axis travel mm 850
Y axis travel mm 500
Z axis travel mm 550
Max load admitted on the work table kg 500
Spindle-table distance mm 100 - 650
T-slots mm 1-5
Distance between slots mm 100
Main spindle cone BT40
Column distance - spindle center mm 582
Speed ​​range rpm 20-10000
Main engine power at S6 kW fifteen
Cone balancing G1
Spindle precision mm ±0.005
Dynamic precision mm ±0.007
Standard tool holder MSA403 BT40
X axis servomotor power kW 1.8
Y axis servomotor power kW 1.8
Z axis servomotor power kW 2.5
X axis rapid feed m/min 48
Y axis rapid feed m/min 48
Z axis rapid feed m/min 32
Work progress mm/min 12000
Tool magazine type Double arm
Tool changer type Random
Tool capacity pc 24
Day. max. of tools with adjacent tool mm 78
Day. max without adjacent tool mm 120
Max weight supported tool kg 8
Max length of tool admitted mm 300
Tire consumption kg 6-8
Electrical consumption kva twenty
Required power 380V±10% 50Hz
Coolant pump flow l/min 40
Optimal ambient temperature range º 0-40
Optimum ambient humidity % 20-80
Fairing type Complete
X/Y/Z positioning accuracy mm ±0.008
X/Y/Z repositioning precision mm ±0.004
Dimensions mm 2460×2355×2860
Weight kg 5500

Data sheet

Characteristics
X/Z axis travel mm 150/ 550
X axis travel mm 150
Z axis travel mm 550
X/Z axis rapid feeds m/min 6/ 8
Max diameter turning mm 360
Max diameter dump truck mm 180
Max diameter cutting mm 220
Max length cutting mm 540
Distance between points mm 690
bar step mm ø 57
Main engine power kW 5.5
Main spindle speed rpm 140-3000
spindle nose ISO 702/I A2-6
tailstock diameter mm 55
Counterpoint route mm 120
Tailstock morse taper MT No. 4
Dimensions (Length x width x height) mm 2150x1260x1600
Weight kg 1700

Data sheet

Characteristics
Brand VURCON
X axis travel mm 210
Z axis travel mm 560
Max diameter turning mm 600
Max diameter dump truck mm 360
Max diameter cutting mm 470
Max length cutting mm 650
Main engine power kW 11/ 15
Main spindle speed rpm 50-4500
spindle nose A2-6
Spindle bearing diameter mm 65
bar step mm 51
Plate size Inch 8
plate hole mm 10"
X/Z axis rapid feeds m/min 30
X/Z axis guides Linear
Turret capacity 8
Square drive size mm 25x25
Max length turning mm 500
Counterpoint route mm 450
Tailstock morse taper TM No. 5
Tailstock movement type Motorized
Spindle opening mm fifty
Guide type Linear
Positioning accuracy for X/Z mm ±0.008
Positioning repeatability for X/Z mm ±0.004
Chip extractor Chain type
Dimensions (Length x width x height) mm 2700x1890x1880
Weight kg 4500
Main servo motor power kW 11/15
X axis servomotor power kW 1.8
Z axis servomotor power kW 1.8

Data sheet

Characteristics
Brand VURCON
X axis travel mm 210
Z axis travel mm 560
Max diameter turning mm 600
Max diameter dump truck mm 360
Max diameter cutting mm 470
Max length cutting mm 650
Main engine power kW 11/ 15
Main spindle speed rpm 50-4500
spindle nose A2-6
Spindle bearing diameter mm 65
bar step mm 51
Plate size Inch 8
plate hole mm 10"
X/Z axis rapid feeds m/min 30
X/Z axis guides Linear
Turret capacity 8
Square drive size mm 25x25
Max length turning mm 500
Counterpoint route mm 450
Tailstock morse taper TM No. 5
Tailstock movement type Motorized
Spindle opening mm fifty
Guide type Linear
Positioning accuracy for X/Z mm ±0.008
Positioning repeatability for X/Z mm ±0.004
Chip extractor Chain type
Dimensions (Length x width x height) mm 2700x1890x1880
Weight kg 4500
Main servo motor power kW 11/15
X axis servomotor power kW 1.8
Z axis servomotor power kW 1.8

Data sheet

Characteristics
Brand VURCON
Version 2000
X axis travel mm 250
Z axis travel mm 1920
X/Z axis rapid feeds m/min 8/12
Max diameter turning mm 510
Max diameter dump truck mm ø 290
Day. max. horizontal turning 6 positions mm ø 460
Distance between points mm 2000
bar step mm ø 87
Main engine power kW 7.5
Main spindle speed rpm 2500
plate hole mm 82
spindle nose A2-8
Turret capacity 6
Square drive size mm 25x25
Shank diameter hydraulic tailstock mm ø 80
tailstock diameter mm ø 75
Counterpoint route mm 150
Tailstock morse taper TM No. 5
Hydraulic tailstock cone MT5
Dimensions (Length x width x height) mm 4200x2100x2200
Weight kg

4400

Data sheet

Characteristics
Brand VURCON
Version 1500
X/Z axis travel mm 275/1000 (1500/2000)
X axis travel mm 275
Z axis travel mm 1500
X/Z axis rapid feeds m/min 6/ 8
Max diameter turning mm 500
Max diameter dump truck mm 280
Day. max. horizontal turning 6 positions mm 350
bar step mm ø 87
Main spindle speed rpm 30 - 3000
plate hole mm 87
spindle nose ISO702/A28
Turret capacity 4/ 6
Square drive size mm 25x25
Shank diameter hydraulic tailstock mm 80
tailstock diameter mm 75
Counterpoint route mm 150
Tailstock morse taper TM No. 5
Hydraulic tailstock cone MT No. 3
Coolant pump power kW 0.15
Dimensions (Length x width x height) mm 3200x1450x1670
Weight kg 3200

Data sheet

Characteristics
Brand VURCON
Version 2000
X axis travel mm 1000
Z axis travel mm 2000
X/Z axis rapid feeds m/min 6/ 8
Max diameter turning mm ø 500
Max diameter dump truck mm ø 280
Day. max. horizontal turning 6 positions mm ø 350
bar step mm ø 87
Main spindle speed rpm 30 - 3000
spindle nose ISO702/A28
Turret capacity 4/ 6
Square drive size mm 25x25
Shank diameter hydraulic tailstock mm ø 80
tailstock diameter mm ø 75
Counterpoint route mm 150
Tailstock morse taper TM No. 5
Hydraulic tailstock cone MT No. 3
Coolant pump power kW 0.15
Dimensions (Length x width x height) mm 3700x1450x1670
Weight kg 3600

Data sheet

Characteristics
Brand VURCON
Version 2000
X axis travel mm 280
Z axis travel mm 2000
Max diameter turning mm 260
Distance between points mm 2000
bar step mm 52
Main engine power kW 11/ 15
Main spindle speed rpm 3500
spindle nose A2-6
Turret capacity 12
Counterpoint route mm 100
Dimensions (Length x width x height) mm 3400x1600x2010
Weight kg 5300
Standard
Standard
